Quality Verified Stone Cutting Tip Diamond Segment for Marble Travertine Limestone

Product Description

  Quality Verified Stone Cutting Tip Diamond Segment for Marble Travertine Limestone Product Description   Diamond Segment for marble cutting, produced by Huazuan Diamond Tool Co., Ltd, is made from high grade diamond powder and metal bond material (Ti, Cr, Ni, Co, etc. ) to form chemical bonds. Diamonds and bond in every layer are carefully designed to rid itself of the prevalence of mechanical grip and reduce the shedding of diamond, which can increase the sharpness, prolong the service life and ensure the cutting stability of diamond segment. We are specialized in making multi layers and sandwich stone cutting segment with various standard sizes suitable for bridge saw or block cutters.

Product Name

Quality Verified Stone Cutting Tip Diamond segment for marble Travertine Limestoneone

Size

24x8x13mm (Specialized in making any sizes of diamond segment, we can make many different kinds of quality and sizes to fit your market and your stone. )

Diameter

900mm blade (other blades 250mm-800mm segments can be made. )

Application

marble cutting tool used for Cutting Marble, ( also other more segments for granite, basalt, sandstone, limestone, lava, concrete etc.)

Feature



1. Fast cutting & long life & Stable performance, High grade of diamonds

2. Different bonds are for different applications & precise segment size

3. Working safe, quiet, and precise, reducing cutting & working time

4. Great adaptability & No chipping



Package

Color box,double blister card,skin packing,white box etc

Supply ability

1000 sets/week(We accept mixed order)

Quality

ISO9001&Gold Supplier

Factory=Quality Control=Competitive Price=Owntechnology=OEM

Quality Verified Stone Cutting Tip Diamond Segment for Marble Travertine Limestone

Granite blade segment dimension

Outer Diameter

Dimension of Teeth

No.of teeth

Inch

mm

length

Thickness

Height



10”

250

40

3.0

12/15/20

17

12”

300

40

3.0

12/15/20

21

14”

350

40

3.2

12/15/20

24

16”

400

40

3.4

12/15/20

28

18”

450

40

4.0

12/15/20

32

20”

500

40

4.2

12/15/20

36

24”

600

40

4.6

12/15/20

42

28”

700

40

5.6

12/15/20

42

32”

800

40

5.6

12/15/20

46

Marble blades segment dimension

10”

250

40

3.0

8/10

18

12”

300

40

3.0

8/10

22

14”

350

40

3.4

8/10

25

16”

400

40

3.6

8/10

29

18”

450

40

4.0

8/10

32

20”

500

40

4.2

8/10

36

24”

600

40

4.6

8/10

42

28”

700

40

5.6

8/10

42

32”

800

40

5.6

8/10

46



Other specifications are available upon request.

   HUAZUAN Advantage   Quality Verified Stone Cutting Tip Diamond Segment for Marble Travertine Limestone Quality Verified Stone Cutting Tip Diamond Segment for Marble Travertine Limestone Quality Verified Stone Cutting Tip Diamond Segment for Marble Travertine Limestone   Application   Diamond cutting tool for marble used for single or multi circular saw blade from 300mm to 3500mm. Diamond segment suitable for all kinds of marble, linestone, travertine and kinds of soft stone without quartz.
Quality Verified Stone Cutting Tip Diamond Segment for Marble Travertine LimestoneQuality Verified Stone Cutting Tip Diamond Segment for Marble Travertine Limestone   Attention for welding:   High frequency silver welded machine is recommended instead of welding by fire. Don’t weld diamond segment for a long time, just a few minutes, otherwise the diamond inside might be damaged because of the high temperature, which will affect the cutting performance of the granite segment greatly.     Our Services   Other specification or design of segment can be ordered by request. Customize formula according to stone features, such as hard, medium-hard or soft. Technical consultation support before and after sales. Packaging & Shipping  Quality Verified Stone Cutting Tip Diamond Segment for Marble Travertine Limestone Quality Verified Stone Cutting Tip Diamond Segment for Marble Travertine Limestone  About US - HUAZUAN Quality Verified Stone Cutting Tip Diamond Segment for Marble Travertine LimestoneQuality Verified Stone Cutting Tip Diamond Segment for Marble Travertine Limestone Quality Verified Stone Cutting Tip Diamond Segment for Marble Travertine LimestoneQuality Verified Stone Cutting Tip Diamond Segment for Marble Travertine Limestone    FAQ Q1:Are you a factory or trading company?
A:We are factory.

Q2:Where is your factory located?How can I visit you?
A:Our factory located in Quanzhou City,Fujian Province,China.You can fly to Xiamen International Air Port or Jinjiang Air Port,and we will you pick you up.Welcome you to visit our factory.   Q3. How is your quality?
A. We have a very seriously control system(PDCA principle and 7S) and . We guarantee the high performance of our products.

Q4.What we should do if your products can not run well?
A:Give us detailed report.Analyze the reason.
Try to find a way to solve the problem.If it's our problem and not possible to solve then will give replacement.   Q5. Do you have different quality for different kind of stone?
A. Yes, according hardness of stone and stone’s feature, we have different typology respectively.     Contact US Quality Verified Stone Cutting Tip Diamond Segment for Marble Travertine Limestone

Contact us if you need more details on Stone Cutting Tip. We are ready to answer your questions on packaging, logistics, certification or any other aspects about Marble Cutting Segment、Diamond Segment For Marble. If these products fail to match your need, please contact us and we would like to provide relevant information.
